SERIES TP: vertical-frame laser tube with 3 chucks

Hymson TP SERIES tube laser cutting system is a THREE chucks laser machine suitable for heavy duty tube and profile working with state-of-the-art technology, with full length cutting and zero scraps. The three-jaw chuck is a brand-new mechanism used to process long and heavy tubes.

High-end performance fiber optic laser cutting machine for TUBES and PROFILES

The TP SERIES is the winning choice for the most demanding industry that requires high cutting performance to obtain surfaces without burrs or flakes, maximum reliability and excellent return on investment. The system, at the top of the range in laser tube cutting, is highly automated, with five-axis linkage, ultra-fast rotation and high-precision positioning. As to the control, the world’s top brand CNC Esa Automotion and the first-class high-power laser are used to make it an advanced numerical control laser tube cutting machine integrating high stability, high precision and high performance. The automation of all operations results in significant time savings and a controlled step-by-step process that is not just depending on the operator’s technical skills. The machine can process a wide variety of shapes, opening up new areas of industrial application.

Model TP 6026 |  Model TP6035

• Automatic loading and unloading system for bulk batches
• Efficient gantry-type structure.
• Honeycomb welded structure with integral plate welding for the highest stability.
• One-piece spindle Ø 260mm or 350mm for higher stability.

Model TP9035

• Working range Ø 20-350 mm or 240x240mm.
• Max bar weight: Kg/m 110 (1000kg/whole tube)
• Automatically loadable bar length: up to 6200 mm ( option 9200mm )
• Maximum workpiece length: 6200 mm fully machined; option 9200mm for longer tubes.

Technical specification SERIES TP
